FRP Tanks & Vessels
Advanced FRP/PP-FRP chemical storage solutions.
Product Overview
Our Industrial FRP Tanks and Vessels are engineered for superior chemical resistance and durability. Manufactured using high-grade FRP (Fiber Reinforced Plastic), PP-FRP, PVC-FRP, and PVDF-FRP, these vessels are the ideal solution for storing corrosive chemicals, acids, and alkalis. Designed to withstand high temperatures and harsh industrial environments, they offer a lightweight yet robust alternative to traditional metal tanks. We utilize advanced filament winding and hand lay-up techniques to ensure structural integrity and leak-proof performance.
Key Features & Specifications
- Material: FRP, PP-FRP, PVC-FRP, PVDF-FRP
- Capacity: Custom sizes from 500L to 100KL+
- Types: Vertical, Horizontal, Rectangular, Cylindrical
- Application: Chemical Storage, Reaction Vessels, Acid Pickling
- Features: High corrosion resistance, UV stabilized, Long service life
Materials & Engineering
We select resin systems and reinforcement grades tailored to resist chemical attack and temperature extremes:
- Isophthalic polyester resin – general chemical service
- Vinyl ester resin (Derakane 411/470) – strong acids and oxidizers
- Bisphenol resin – high temperature and alkali service
- PVDF lining – ultra-aggressive chemicals and high purity
- E-glass and ECR-glass reinforcement for structural strength
Industries & Use Cases
Our FRP Tanks & Vessels solutions are trusted across diverse demanding sectors:
Storage of concentrated acids (sulphuric, hydrochloric, nitric)
Alkali and caustic storage (sodium hydroxide, potassium hydroxide)
Sodium hypochlorite and bleach storage for water treatment
Reaction vessels in pharmaceutical and specialty chemical manufacturing
Electroplating and surface treatment baths
Fertilizer and agrochemical intermediate storage
Potable water and DM water storage with food-grade resins
The GPPL Edge
Why leading manufacturing, chemical, and infrastructure firms partner with us:
Corrosion resistance far exceeds stainless steel for most acids
One-fifth the weight of equivalent MS tanks, reducing civil cost
Molded-in-place internal fittings eliminate leak paths
Service life of 20+ years with minimal maintenance
UV-stabilized outer layer prevents resin degradation in outdoor use
Lower total cost of ownership than SS316 for corrosive service
Frequently Asked Questions
Answers to common queries regarding design, sizing, compliance, and deployment.
What is the maximum capacity you can manufacture for FRP tanks?
We routinely fabricate FRP tanks from 500 litres up to 100,000 litres (100 KL). Larger site-fabricated tanks exceeding 200 KL are also possible on request.
How long does an FRP chemical storage tank last?
With correct resin selection for the stored chemical, FRP tanks from Ghaziabad Polymers typically deliver 20+ years of service life. Outdoor UV-stabilized tanks retain structural integrity well past that timeline.
Are your FRP tanks suitable for hydrochloric acid and sulphuric acid?
Yes. For HCl we supply vinyl-ester lined FRP tanks; for concentrated H₂SO₄ we provide PVC-FRP or PVDF-FRP lined vessels engineered to handle the specific concentration and temperature.
Do you provide FRP tanks for potable water storage?
Yes, we manufacture food-grade FRP water tanks using FDA-approved isophthalic and food-grade resins suitable for potable water storage in industrial and commercial applications.
Can FRP tanks be installed outdoors?
Absolutely. All our outdoor FRP tanks receive a UV-stabilized gel-coat top layer that prevents resin degradation from sunlight. They perform well in Indian outdoor conditions for decades.
Interested in FRP Tanks & Vessels?
Our engineers can design and manufacture a custom solution tailored to your plant's specific chemical composition, temperature, and space requirements.
